Photovoltaik Hybrid

POOL ELECTRO HYBRID

Solarabsorber & Photovoltaik

Pool Heating and Photovoltaik in One

Solar swimming pool warming and Pv electrical energy

WITH THE SAME Solar system

Our COEX TPE solar absorber for swimming pool heating with a thin layer of photovoltaic film on top brings swimming pool heat and photovoltaic electricity at the same time.

You get a double use at once!


The electric hybrid for the pool can be installed on any roof without complicated procedures of fixing, JUST GLUEING.

System Solaranlage
Solar Dach

The „lower part“: Solkav Solarabsorber CoEX TPE

The Solkav CoEX TPE is an exposed solar absorber system that is characterized as follows:

Can be installed on any roof

Is made up individually to your roof dimensions

Pool water can flow through it directly

Increases the average temperature in the pool by 5K at approx. 80% to 100% design (of the pool surface).

The system is individually tailored to your roof dimensions. In case of doubt "directly on the roof". You can also use special shapes like on walls or embankments appropriate. In this case, the solar absorber is not glued, but attached to the wall or a small substructure with straps. Our experts will be happy to advise you on the installation.

That means a seasonal increase of 60 days and more.


Can be built as private systems up to huge roof systems for outdoor and indoor swimming pools of all sizes.

Badetemperatur
flaches Solardach

The „Upper part“: Thin layer Photovoltaic foil


The eFlex is a rom of flexible and slim CIGS-Solar-PV-Modules. The modules can be glued to all surfaces with limited load-bearing capacity, on curved surfaces. The modules are matched to the solar absorber dimensions and glued to the solar absorber on site after the solar absorber has been installed in a second step. The modules are made of high quality materials that provide long-term performance and are based on a unique technology to achieve high performance in targeted applications.

Characteristics

Very low weight, <2 kg / m2

Applicable on curved surfaces - bendable in a radius of 20 cm

Super thin (<2 mm) and aerodynamic

High energy yield through shadow tolerance and temperature stabilit

Beautiful aesthetics - uniform design in black

Robust and vibration-proof - free of micro-cracks

Solardach

Performance data PV

The photovoltaic system provides nominal output values of 9.5% of the solar radiation; that is 60% compared to panel systems. But without additional space requirements and as one installation together with swimming pool heating.

Leistung
Energieausbeute

The combination effects hybrid

The PV energy yield is normally between 90% and 100% depending on the roof shape and the associated angle of incidence. The swimming pool heating switches on the cooling turbo.

After the photovoltaic gets weaker when the panel gets hot, the pool heat dissipation INCREASES the yield and electrical energy!!!! Unfortunately, it is not the “perpetuum Mobile” machine: Unfortunately, what you use solar as photovoltaics (10%) + the loss of insulation effectiveness cannot be used again as solar swimming pool heat.

Therefore, please assume the following key data for installation / use:

M² need for solar heating swimming pool: + 35% to achieve the 5K swimming pool heating; thus e.g. instead of 20 m² = 28 m² in the future

Photovoltaics 9.5% are safely achieved through the cooling gain, if not exceeded

P.a. in Central Europe: 100 KWh per m²

At a supplier cost of 0.25 cents: Savings in electrical energy: 25 euros / m² p.a.

How to use the PV electricity

Feeding into public system at a low fixed tariff was yesterday!

Preferably an electric car?

Feed in according to the new EEG and "get it back".

Caching?

Ask us; we will make you an attractive usage suggestion depending on your individual situation.
